Bilstein SN2 Series shock absorbers feature a steel, smooth body design utilizing the 46mm monotube technology (piston and piston band sold separately) designed for motorsports applications. These shock absorbers are available in non-, single and double adjustable configurations in optimized lengths and can also be converted to a coilover design (kit sold separately). SN2 Series shock absorbers are ideal for racers whose sanctioning rules require steel body shock absorbers but allow for a user rebuildable design and aluminum end caps.
Additional Attributes:
GTIN: 00651860924823
Adjustable Damping: Non-Adjustable
Body Design: Threaded Body Screw Top (Coilover)
Body Material: Steel
Boot Included: No
Collapsed Length (IN): 12.99
Collapsed Length (MM): 330.0
Extended Length (IN): 19.80
Extended Length (MM): 503.0
Finish: Zinc Plated
Internal Design: Monotube
Lower Mount Type: 1/2in Heim
PartType: Shocks / Struts
Piston Diameter: 46mm
Piston Type: Linear
Prop 65 (Y/N): Y
Prop 65 – Short Label: WARNING: Cancer & Reproductive Harm – www.P65Warnings.ca.gov
Segment: Motorsports
Series: SN2 Series
Spring Max Travel (IN): 6.81
Spring Seat Included: No
Upper Mount Type: 1/2in Heim
Extended Information:
Emissions : Emissions Compliance Exempt
Life Cycle Status: Available To Order
Packaging:
Quantity of Each: 1.0
Package UOM: EA
Dimension: 22.5000 x 3.0000 x 3.0000 inches
Weight: 7.0000 PG
USA SDS_Shock_Air Spring_V2_EN
