Bilstein AS2 Series shock absorbers are designed for motorsports applications and provide the user with the option to rebuild them. The modular aluminum design is offered in non-, single and double adjustable configurations which provide superior on-vehicle tuning capabilities. The threaded body provides precise height adjustments for coilover setups and dissipates heat quickly. The hard anodized coating reduces internal friction and improves strength and durability (pistons, piston bands and heims are sold separately to allow for a variety of combinations). AS2 Series shock absorbers are ideal for racers demanding a lightweight design with upgrade capability.
Additional Attributes:
GTIN: 00651860923024
Adjustable Damping: Single Adjustable – Rebound
Body Design: Threaded Body Screw Top (Coilover)
Body Material: Aluminum
Boot Included: No
Collapsed Length (IN): 12.22
Collapsed Length (MM): 310.3
Extended Length (IN): 18.60
Extended Length (MM): 472.5
Finish: Clear Anodized
Internal Design: Monotube
Lower Mount Type: 1/2in teflon heim
PartType: Shocks / Struts
Piston Diameter: 46mm
Piston Type: Sold Separately
Prop 65 (Y/N): Y
Prop 65 – Short Label: WARNING: Cancer & Reproductive Harm – www.P65Warnings.ca.gov
Segment: Motorsports
Series: AS2 Series
Spring Hardware: B4-MKT-0008A00
Spring Hardware 2: E4-FT4-Z060A00
Spring Hardware 3: E4-MSG-0083A00
Spring Max Travel (IN): 6.38
Spring Seat Included: Yes
Upper Mount Type: 1/2in teflon heim
Extended Information:
Emissions : Emissions Compliance Exempt
Life Cycle Status: Available To Order
Packaging:
Quantity of Each: 1.0
Package UOM: EA
Dimension: 29.5000 x 3.5000 x 3.5000 inches
Weight: 7.0000 PG
USA SDS_Shock_Air Spring_V2_EN
